B39202B4309P810
lmages are for reference only.B39202B4309P810
FILTER SAW 1.95GHZ 5SMD
Datasheet5-SMD, No Lead
54,625 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1.95GHz Frequency Cellular, WCDMA RF SAW Filter (Surface Acoustic Wave) 2.3dB 60MHz Bandwidth 5-SMD, No Lead
B39202B4309P810
| Category | Filters - SAW Filters - |
| Manufacturer | Qualcomm (RF front-end (RFFE) filters) |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Bandwidth | 60MHz |
| Insertion Loss | 2.3dB |
| Ratings | AEC-Q200 |
| Applications | Cellular, WCDMA |
| Mounting Type | Surface Mount |
| Package / Case | 5-SMD, No Lead |
| Height (Max) | 0.016" (0.40mm) |
| Size / Dimension | 0.055" L x 0.043" W (1.40mm x 1.10mm) |
| Frequency - Center | 1.95GHz |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | B39202B4305F210 | B39202B4335P810 | B39202B4366P810 | B39202B4381P810 |
| Manufacturer | Qualcomm (RF front-end (RFFE) filters) | Qualcomm (RF front-end (RFFE) filters) | Qualcomm (RF front-end (RFFE) filters) | Qualcomm (RF front-end (RFFE) filters) |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FILTER SAW 1.96GHZ 5SMD | FILTER SAW CU-FRAME 5SMD | RF FILTER SAW SMD QCS5P | FILTER SAW 1.8425/1.96GHZ 10SMD |
| Series | - | - | B4336 | B4381 |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
