Product CatalogPart Number
B514F-2T
Manufacturer
Sensata-CrydomDescription
MOD DIODE SCR 25A 480VAC .250"QC
Datasheet
DatasheetPackage
Module
In Stock
58,331 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
B514F-2T
B514F-2T
lmages are for reference only.Payment Methods
Delivery Services
SCR Module 1.2 kV Bridge, Single Phase - SCRs/Diodes (Layout 1) Chassis Mount Module
Quick Inquiry
B514F-2T
Specifications
| Category | Discrete Semiconductor Products - Thyristors - SCRs Modules |
| Manufacturer | Sensata-Crydom |
| Series | B-2T |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Structure | Bridge, Single Phase - SCRs/Diodes (Layout 1) |
| Number of SCRs, Diodes | 2 SCRs, 2 Diodes |
| Voltage - Off State | 1.2 kV |
| Current - On State (It (AV)) (Max) | - |
| Current - On State (It (RMS)) (Max) | - |
| Voltage - Gate Trigger (Vgt) (Max) | 2.5 V |
| Current - Gate Trigger (Igt) (Max) | 60 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 250A @ 60Hz |
| Current - Hold (Ih) (Max) | - |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Base Product Number | B514F |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
|
|
 |
| Part Number | B514F-2 | B514F-2 | B514F-2T | B514FSE-2T |
| Manufacturer | Sensata-Crydom | Sensata-Crydom | Sensata-Crydom | Sensata-Crydom |
| RoHS Status | RoHS Compliant | RoHS Compliant | ||
| Description | MOD DIODE SCR 25A 480VAC ISO QC | MOD DIODE SCR 25A 480VAC ISO QC | MOD DIODE SCR 25A 480VAC .250"QC | MOD DIODE SCR 25A 480VAC .250"QC |
| Series | B-2 | B-2 | B-2T | B-2T |
| Packaging | Bulk | Bulk | Bulk | Bulk |
