B78148T1122K9
lmages are for reference only.B78148T1122K9
FIXED IND 1.2UH 610MA 250MOHM TH
DatasheetRadial, Vertical Cylinder
80,193 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1.2 µH Unshielded Drum Core, Wirewound Inductor 610 mA 250mOhm Max Radial, Vertical Cylinder
B78148T1122K9
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | EPCOS - TDK Electronics |
| Series | MCC |
| Packaging | Tape & Box (TB) |
| RoHS Status | ROHS3 Compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 1.2 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 610 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 250mOhm Max |
| Q @ Freq | 40 @ 7.96MHz |
| Frequency - Self Resonant | 170MHz |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Inductance Frequency - Test | 7.96 MHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder |
| Supplier Device Package | - |
| Size / Dimension | 0.130" Dia (3.30mm) |
| Height - Seated (Max) | 0.386" (9.80mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
|
| Part Number | B78148T1103K9 | B78148T1152K9 | B78148T1153K9 | B78148T1222K9 |
| Manufacturer | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 10UH 230MA 1.7 OHM TH | FIXED IND 1.5UH 570MA 300MOHM TH | FIXED IND 15UH 185MA 2.7 OHM TH | FIXED IND 2.2UH 520MA 350MOHM TH |
| Series | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| Packaging | Tape & Box (TB) | Tape & Box (TB) | Tape & Box (TB) | Tape & Box (TB) |
