B82747S4203A020
lmages are for reference only.B82747S4203A020
CMC 1.3MH 20A 3LN TH
DatasheetVertical, 6 PC Pin
72,663 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1.3 mH @ 10 kHz 3 Line Common Mode Choke Through Hole 20A DCR 5.2mOhm (Typ)
B82747S4203A020
| Category | Filters - Common Mode Chokes - |
| Manufacturer | EPCOS - TDK Electronics |
| Series | B82747 |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 3 |
| Inductance @ Frequency | 1.3 mH @ 10 kHz |
| Current Rating (Max) | 20A |
| DC Resistance (DCR) (Max) | 5.2mOhm (Typ) |
| Voltage Rating - DC | - |
| Voltage Rating - AC | 440/250V |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 2.323" Dia x 1.102" W (59.00mm x 28.00mm) |
| Height (Max) | 2.362" (60.00mm) |
| Package / Case | Vertical, 6 PC Pin |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
|
| Part Number | B82747S4253A040 | B82745C2A10 | B82745C2A13 | B82745C5A7 |
| Manufacturer | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CMC 850UH 30A 3LN TH | CMC 330UH 100A 3LN CHAS MNT | CMC 120UH 200A 3LN CHAS MNT | CMC 1.3MH 50A 3LN CHAS MNT |
| Series | B82747 | B82745 | B82745 | B82745 |
| Packaging | Tray | Tray | Tray | Tray |
