BA33B00FP-E2
lmages are for reference only.BA33B00FP-E2
IC REG LINEAR POS ADJ TO252
DatasheetTO-252-3, DPAK (2 Leads + Tab), SC-63
98,366 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Adjustable (Fixed) 2 Output 1A, 500mA TO-252
BA33B00FP-E2
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Rohm Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Adjustable (Fixed) |
| Number of Regulators | 2 |
| Voltage - Input (Max) | 16V |
| Voltage - Output (Min/Fixed) | 1.267V (3.3V) |
| Voltage - Output (Max) | 5V |
| Voltage Dropout (Max) | 0.5V @ 500mA, 0.5V @ 200mA |
| Current - Output | 1A, 500mA |
| Current - Quiescent (Iq) | 0.8 mA |
| PSRR | 58dB (120Hz), 55dB (120Hz) |
| Control Features | - |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Supplier Device Package | TO-252 |
| Base Product Number | BA33B00 |
| Current - Supply (Max) | 1.4 mA |
| Product Attribute |  |
 |
 |
 |
| Part Number | BA00ASFP-E2 | BA00AST | BA00BC0WCP-V5E2 | BA00BC0WF-E2 |
| Manufacturer | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LINEAR POS ADJ 1A TO252-5 | IC REG LIN POS ADJ 1A TO220-5 FP | IC REG LIN POS ADJ 1A TO220CP-V5 | IC REG LINEAR POS ADJ 500MA 8SOP |
| Series | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
