Product CatalogPart Number
BAV20WS_R1_00001
Manufacturer
Panjit International Inc.Description
SOD-323, SWITCHING
Datasheet
DatasheetPackage
SC-90, SOD-323F
In Stock
12,394 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
BAV20WS_R1_00001
BAV20WS_R1_00001
lmages are for reference only.Payment Methods
Delivery Services
Diode 150 V 200mA Surface Mount SOD-323
Quick Inquiry
BAV20WS_R1_00001
Specifications
| Category | Discrete Semiconductor Products - Diodes - Rectifiers |
| Manufacturer | Panjit International Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | Standard |
| Voltage - DC Reverse (Vr) (Max) | 150 V |
| Current - Average Rectified (Io) | 200mA |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 100 mA |
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 50 ns |
| Current - Reverse Leakage @ Vr | 100 nA @ 150 V |
| Capacitance @ Vr, F | 5pF @ 0V, 1MHz |
| Mounting Type | Surface Mount |
| Package / Case | SC-90, SOD-323F |
| Supplier Device Package | SOD-323 |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Base Product Number | BAV20 |
| Grade | - |
| Qualification | - |
