BD4271EFJ-CE2
lmages are for reference only.BD4271EFJ-CE2
550MA OUTPUT LDO REGULATOR WITH
Datasheet8-SOIC (0.154", 3.90mm Width) Exposed Pad
83,218 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 550mA 8-HTSOP-J
BD4271EFJ-CE2
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Rohm Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 45V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.5V @ 300mA |
| Current - Output | 550mA |
| Current - Quiescent (Iq) | 150 µA |
| PSRR | 60dB (120Hz) |
| Control Features | Enable, Reset, Watchdog |
| Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad |
| Supplier Device Package | 8-HTSOP-J |
| Base Product Number | BD4271 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | BD42540FJ-CE2 | BD4269EFJ-CE2 | BD4269FJ-CE2 | BD4269UEFJ-CE2 |
| Manufacturer | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LIN POS ADJ 70MA 8-SOP-J | IC REG LIN POS ADJ 300MA 8HTSOP | IC REG LIN POS ADJ 200MA 8-SOP-J | 300MA OUTPUT LDO REGULATOR WITH |
| Series | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
