BD9285F-GE2
lmages are for reference only.BD9285F-GE2
IC LED DRIVER CTRLR PWM 18SOP
Datasheet18-SOIC (0.213", 5.40mm Width)
23,378 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 1 Output DC DC Controller Step-Up (Boost) Analog, PWM Dimming 18-SOP
BD9285F-GE2
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Rohm Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Controller |
| Topology | Step-Up (Boost) |
| Internal Switch(s) | No |
| Number of Outputs | 1 |
| Voltage - Supply (Min) | 9V |
| Voltage - Supply (Max) | 18V |
| Voltage - Output | - |
| Current - Output / Channel | - |
| Frequency | 150kHz |
| Dimming | Analog, PWM |
| Applications | Backlight |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 18-SOIC (0.213", 5.40mm Width) |
| Supplier Device Package | 18-SOP |
| Base Product Number | BD9285 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | BD18378EFV-ME2 | BD18337EFV-ME2 | BD1603NUV-E2 | BD6061GUT-E2 |
| Manufacturer | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC LED DRV LIN PWM 50MA 28HTSSOP | IC LED DRVR PS PWM HTSSOP-B16 | IC LED DRVR RGLTR VSON010V3030 | IC LED DRVR RGLTR 270MA VCSP60N1 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
