BFR520,235
lmages are for reference only.BFR520,235
RF TRANS NPN 15V 9GHZ TO236AB
DatasheetTO-236-3, SC-59, SOT-23-3
40,107 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Transistor NPN 15V 70mA 9GHz 300mW Surface Mount SOT-23 (TO-236AB)
BFR520,235
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | NXP USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Transistor Type | NPN |
| Voltage - Collector Emitter Breakdown (Max) | 15V |
| Frequency - Transition | 9GHz |
| Noise Figure (dB Typ @ f) | 1.1dB ~ 2.1dB @ 900MHz |
| Gain | - |
| Power - Max | 300mW |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 60 @ 20mA, 6V |
| Current - Collector (Ic) (Max) | 70mA |
| Operating Temperature | 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23 (TO-236AB) |
| Base Product Number | BFR52 |
| Product Attribute |  |
 |
 |
 |
| Part Number | BFR520,215 | BFR505,215 | BFR505215 | BFR505T,115 |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | Not applicable | ROHS3 Compliant |
| Description | RF TRANS NPN 15V 9GHZ TO236AB | RF TRANS NPN 15V 9GHZ TO236AB | SMALL SIGNAL BIPOLAR TRANSISTOR | RF TRANS NPN 15V 9GHZ SC75 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR) |
