BLCR-L01D-U2
lmages are for reference only.BLCR-L01D-U2
SENSOR 0.04PSIG 0.12" .008V
Datasheet6-SMD, Gull Wing, Top Port
76,795 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Pressure Sensor ±0.04PSI (±0.25kPa) Gauge Male - 0.12" (3mm) Tube 0 mV ~ 8 mV 6-SMD, Gull Wing, Top Port
BLCR-L01D-U2
| Category | Sensors, Transducers - Pressure Sensors-Transducers - |
| Manufacturer | Amphenol All Sensors Corporation |
| Series | BLCR |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | BLCR-L01D |
| Applications | Board Mount |
| Pressure Type | Gauge |
| Operating Pressure | ±0.04PSI (±0.25kPa) |
| Output Type | Analog Voltage |
| Output | 0 mV ~ 8 mV |
| Accuracy | ±0.5% |
| Voltage - Supply | 1.8V ~ 3.3V |
| Port Size | Male - 0.12" (3mm) Tube |
| Port Style | Barbless |
| Features | - |
| Termination Style | Gull Wing |
| Maximum Pressure | 3.63PSI (25kPa) |
| Operating Temperature | -25°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, Gull Wing, Top Port |
| Supplier Device Package | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | BLCR-L01D-D4 | BLCR-L05D-D4 | BLCR-L05D-U2 | BLCR-L05D-U2 |
| Manufacturer | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | SENSOR 0.04PSID 0.12" .008V | SENSOR 0.18PSID 0.12" .024V | SENSOR 0.18PSIG 0.12" .024V | SENSOR 0.18PSIG 0.12" .024V |
| Series | BLCR | BLCR | BLCR | BLCR |
| Packaging | Tube | Tube | Tube | Tube |
