BMR4742001/001
lmages are for reference only.BMR4742001/001
6-15VIN; 0.6-3.3VOUT; 80A; NON-I
Datasheet15-SIP Module
88,674 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Non-Isolated PoL Module DC DC Converter 1 Output 0.6 ~ 3.3V 80A 6V - 15V Input
BMR4742001/001
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Flex Power Modules |
| Series | - |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 6V |
| Voltage - Input (Max) | 15V |
| Voltage - Output 1 | 0.6 ~ 3.3V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 80A |
| Power (Watts) | 264 W |
| Applications | ITE (Commercial) |
| Features | Adjustable Output, PMBus™, Remote On/Off, Remote Sense, Standby Output |
| Operating Temperature | -40°C ~ 125°C (With Derating) |
| Efficiency | 95.1% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 15-SIP Module |
| Size / Dimension | 1.30" L x 0.34" W x 0.75" H (33.0mm x 8.6mm x 19.0mm) |
| Supplier Device Package | - |
| Control Features | Enable, Active High |
| Approval Agency | cURus, UL |
| Standard Number | 62368-1 |
| Base Product Number | - |
| Voltage - Isolation | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | BMR4500002/020 | BMR4501002/020 | BMR4510002/020 | BMR4511002/020 |
| Manufacturer | Flex Power Modules | Flex Power Modules | Flex Power Modules | Flex Power Modules |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DC DC CONVERTER 0.6-5.5V 110W | DC DC CONVERTER 0.6-5.5V 110W | DC DC CONVERTER 0.6-3.6V 144W | DC DC CONVERTER 0.6-3.6V 144W |
| Series | Flex Power Modules | Flex Power Modules | Flex Power Modules | Flex Power Modules |
| Packaging | Tray | Tray | Tray | Tray |
