Product CatalogPart Number
BTS117AKSA1
Manufacturer
Infineon TechnologiesDescription
IC PWR SWITCH
Datasheet
DatasheetPackage
TO-220-3
In Stock
85,124 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
BTS117AKSA1
BTS117AKSA1
lmages are for reference only.Payment Methods
Delivery Services
Power Switch/Driver 1:1 N-Channel 3.5A PG-TO220-3-1
Quick Inquiry
BTS117AKSA1
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Switch Type | General Purpose |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | Low Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 60V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 3.5A |
| Rds On (Typ) | 80mOhm |
| Input Type | Non-Inverting |
| Features | Auto Restart, Slew Rate Controlled |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | PG-TO220-3-1 |
| Package / Case | TO-220-3 |
| Base Product Number | BTS117 |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | BTS117 | BTS117 E3045A | BTS117BKSA1 | BTS117E3044ANTMA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | IC PWR SWITCH N-CHAN 1:1 TO220-3 | IC PWR SWITCH N-CHAN 1:1 TO220-3 | IC PWR SWITCH N-CHAN 1:1 TO220-3 | IC PWR SWITCH N-CHAN 1:1 TO220-3 |
| Series | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Packaging | Tube | Tape & Reel (TR) | Tube | Tape & Reel (TR) |
