BTS700121ESPXUMA2
lmages are for reference only.BTS700121ESPXUMA2
PROFET PG-TSDSO-24
Datasheet24-TSSOP (0.154", 3.90mm Width) Exposed Pad
39,961 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Power Switch/Driver 1:1 N-Channel 31.3A PG-TSDSO-24-32
BTS700121ESPXUMA2
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Switch Type | Relay, Solenoid Driver |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | - |
| Voltage - Load | 4.1V ~ 28V |
| Voltage - Supply (Vcc/Vdd) | 4.1V ~ 28V |
| Current - Output (Max) | 31.3A |
| Rds On (Typ) | 1.4mOhm |
| Input Type | Non-Inverting |
| Features | Slew Rate Controlled |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, Reverse Battery, UVLO |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-TSDSO-24-32 |
| Package / Case | 24-TSSOP (0.154", 3.90mm Width) Exposed Pad |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | BTS700121ESPXUMA1 | BTS700151ESPXUMA1 | BTS700151ESPXUMA2 | BTC30010-1TAA |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | Not applicable | |
| Description | PROFET PG-TSDSO-24 | PROFET PG-TSDSO-24 | PROFET PG-TSDSO-24 | BUFFER/INVERTER PERIPHL DRIVER |
| Series | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Bulk |
