BU52055GWZ-E2
lmages are for reference only.BU52055GWZ-E2
MAGNETIC SWITCH OMNIPOL UCSP35L1
Datasheet4-XFBGA, CSPBGA
42,435 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Digital Switch Omnipolar Switch Push-Pull Hall Effect UCSP35L1
BU52055GWZ-E2
| Category | Sensors, Transducers - Magnetic Sensors - Switches Solid State |
| Manufacturer | Rohm Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Function | Omnipolar Switch |
| Technology | Hall Effect |
| Polarization | North Pole, South Pole |
| Sensing Range | ±5.5mT Trip, ±1.5mT Release |
| Test Condition | 25°C |
| Voltage - Supply | 1.65V ~ 3.6V |
| Current - Supply (Max) | 8µA |
| Current - Output (Max) | 500µA |
| Output Type | Push-Pull |
| Features | - |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | UCSP35L1 |
| Package / Case | 4-XFBGA, CSPBGA |
| Base Product Number | BU52055 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | BU52001GUL-E2 | BU52002GUL-E2 | BU52003GUL-E2 | BU52004GUL-E2 |
| Manufacturer | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MAG SWITCH OMNIPOLAR 4VCSP50L1 | MAG SWITCH UNIPOLAR 4VCSP50L1 | MAG SWITCH UNIPOLAR 4VCSP50L1 | MAG SWITCH OMNIPOLAR 4VCSP50L1 |
| Series | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
