Product CatalogPart Number
BXA40-24S05
Manufacturer
ARTESYN / Advanced EnergyDescription
DC DC CONVERTER 5V 40W
Datasheet
DatasheetPackage
9-DIP Module
In Stock
96,338 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
BXA40-24S05
BXA40-24S05
lmages are for reference only.Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 5V 8A 18V - 36V Input
Quick Inquiry
BXA40-24S05
Specifications
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | ARTESYN / Advanced Energy |
| Series | BXA40 (40W) |
| Packaging | - |
| RoHS Status | RoHS non-compliant |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 18V |
| Voltage - Input (Max) | 36V |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 8A |
| Power (Watts) | 40 W |
| Applications | ITE (Commercial) |
| Features | Remote On/Off, OVP, SCP |
| Operating Temperature | -40°C ~ 105°C |
| Efficiency | 81% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 9-DIP Module |
| Size / Dimension | 2.20" L x 2.20" W x 0.50" H (55.9mm x 55.9mm x 12.7mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | - |
| Voltage - Isolation | 1.5 kV |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | BXA40-48T05-12 | BP5277-12 | B0315XT-1WR3 | B048T240M30 |
| Manufacturer | ARTESYN / Advanced Energy | Rohm Semiconductor | Mornsun America, LLC | Vicor Corporation |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | DC DC CONVERTER 5V +/-12V 40W | DC DC CONVERTER 12V 6W | DC DC CONVERTER 15V 1W | DC DC CONVERTER 24V 300W |
| Series | ARTESYN / Advanced Energy | Rohm Semiconductor | Vicor Corporation | |
| Packaging | Tray | B0315XT-1WR3 (1W) | Tray |
