BZM55B3V0-TR3
lmages are for reference only.BZM55B3V0-TR3
DIODE ZENER 3V 500MW MICROMELF
Datasheet2-SMD, No Lead
19,297 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Zener Diode 3 V 500 mW Surface Mount MicroMELF
BZM55B3V0-TR3
| Category | Discrete Semiconductor Products - Diodes - Zener |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | BZM55 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Voltage - Zener (Nom) (Vz) | 3 V |
| Tolerance | - |
| Power - Max | 500 mW |
| Impedance (Max) (Zzt) | 600 Ohms |
| Current - Reverse Leakage @ Vr | 4 µA @ 1 V |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 200 mA |
| Operating Temperature | -65°C ~ 175°C |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Mounting Type | Surface Mount |
| Package / Case | 2-SMD, No Lead |
| Supplier Device Package | MicroMELF |
| Base Product Number | BZM55B3V0 |
| Product Attribute |  |
 |
 |
 |
| Part Number | BZM55B3V0-TR | BZM55B30-TR | BZM55B30-TR3 | BZM55B33-TR |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DIODE ZENER 3V 500MW MICROMELF | DIODE ZENER 30V 500MW MICROMELF | DIODE ZENER 30V 500MW MICROMELF | DIODE ZENER 33V 500MW MICROMELF |
| Series | BZM55 | BZM55 | BZM55 | BZM55 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
