BZT55A20-GS08
lmages are for reference only.BZT55A20-GS08
DIODE ZENER 20V 500MW SOD80
DatasheetSOD-80 Variant
48,094 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Zener Diode 20 V 500 mW ±1% Surface Mount SOD-80 QuadroMELF
BZT55A20-GS08
| Category | Discrete Semiconductor Products - Diodes - Zener |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Voltage - Zener (Nom) (Vz) | 20 V |
| Tolerance | ±1% |
| Power - Max | 500 mW |
| Impedance (Max) (Zzt) | 55 Ohms |
| Current - Reverse Leakage @ Vr | 100 nA @ 15 V |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 200 mA |
| Operating Temperature | 175°C |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Mounting Type | Surface Mount |
| Package / Case | SOD-80 Variant |
| Supplier Device Package | SOD-80 QuadroMELF |
| Base Product Number | BZT55 |
| Product Attribute |  |
 |
 |
|
| Part Number | BZT55A20-GS18 | BZT03C10-TAP | BZT03C10-TR | BZT03C100-TAP |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DIODE ZENER 20V 500MW SOD80 | DIODE ZENER 10V 1.3W SOD57 | DIODE ZENER 10V 1.3W SOD57 | DIODE ZENER 100V 1.3W SOD57 |
| Series | - | BZT03 | BZT03 | BZT03 |
| Packaging | Tape & Reel (TR) | Tape & Box (TB) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Box (TB) |
