C3M0016120D
Manufacturer
Wolfspeed, Inc.Description
SICFET N-CH 1200V 115A TO247-3
Datasheet
DatasheetPackage
TO-247-3
In Stock
48,555 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
C3M0016120D
C3M0016120D
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 1200 V 115A (Tc) 556W (Tc) Through Hole TO-247-3
Quick Inquiry
C3M0016120D
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Wolfspeed, Inc. |
| Series | C3M™ |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | SiCFET (Silicon Carbide) |
| Drain to Source Voltage (Vdss) | 1200 V |
| Current - Continuous Drain (Id) @ 25°C | 115A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 15V |
| Rds On (Max) @ Id, Vgs | 22.3mOhm @ 75A, 15V |
| Vgs(th) (Max) @ Id | 3.6V @ 23mA |
| Vgs (Max) | +15V, -4V |
| Input Capacitance (Ciss) (Max) @ Vds | 6085 pF @ 1000 V |
| FET Feature | - |
| Power Dissipation (Max) | 556W (Tc) |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-247-3 |
| Package / Case | TO-247-3 |
| Base Product Number | C3M0016120 |
| Gate Charge (Qg) (Max) @ Vgs | 207 nC @ 15 V |
| Grade | - |
| Qualification | - |
