CCSPG1060N TR PBFREE
lmages are for reference only.CCSPG1060N TR PBFREE
100V, 60A, N-CHANNEL CHIP SCALE
Datasheet8-XFLGA, CSP
54,342 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 100 V 60A (Tc) 300W (Tc) Surface Mount 8-CSP (3.5x2.13)
CCSPG1060N TR PBFREE
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Central Semiconductor Corp |
| Series | * |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | GaNFET (Gallium Nitride) |
| Drain to Source Voltage (Vdss) | 100 V |
| Current - Continuous Drain (Id) @ 25°C | 60A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 5V |
| Rds On (Max) @ Id, Vgs | 5.5mOhm @ 25A, 5V |
| Vgs(th) (Max) @ Id | 2.5V @ 9mA |
| Vgs (Max) | +6V, -4V |
| Input Capacitance (Ciss) (Max) @ Vds | 1000 pF @ 50 V |
| FET Feature | - |
| Power Dissipation (Max) | 300W (Tc) |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-CSP (3.5x2.13) |
| Package / Case | 8-XFLGA, CSP |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 9.2 nC @ 5 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | CCSPG1510N TR PBFREE | CCSPG1560N TR PBFREE | BS170PSTOA | AUIRF4104S |
| Manufacturer | Central Semiconductor Corp | Central Semiconductor Corp | Diodes Incorporated | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | SURFACE MOUNT MOSFET | SURFACE MOUNT MOSFET | MOSFET N-CH 60V 270MA E-LINE | MOSFET N-CH 40V 75A D2PAK |
| Series | - | - | - | HEXFET® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tube |
