CD4002BD
lmages are for reference only.CD4002BD
IC GATE NOR 2CH 4-INP 14SOIC
Datasheet14-SOIC (0.154", 3.90mm Width)
56,959 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
NOR Gate IC 2 Channel 14-SOIC
CD4002BD
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | Harris Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Base Product Number | CD4002 |
| Logic Type | NOR Gate |
| Number of Circuits | 2 |
| Number of Inputs | 4 |
| Features | - |
| Voltage - Supply | 3V ~ 18V |
| Current - Quiescent (Max) | 5 µA |
| Current - Output High, Low | 6.8mA, 6.8mA |
| Input Logic Level - Low | 1.5V ~ 4V |
| Input Logic Level - High | 3.5V ~ 11V |
| Max Propagation Delay @ V, Max CL | 90ns @ 15V, 50pF |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-SOIC |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | CD4002BCN | CD4002BE | CD4002BE | CD4002BM |
| Manufacturer | onsemi | Texas Instruments | Harris Corporation | Texas Instruments |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | IC GATE NOR 2CH 4-INP 14MDIP | IC GATE NOR 2CH 4-INP 14DIP | IC GATE NOR 2CH 4-INP 14DIP | IC GATE NOR 2CH 4-INP 14SOIC |
| Series | 4000B | 4000B | 4000B | 4000B |
| Packaging | Bag | Tube | Tube | Tube |
