CD54AC109F3A
lmages are for reference only.CD54AC109F3A
DUAL POSITIVE-EDGE TRIGGERED J-K
Datasheet16-CDIP (0.300", 7.62mm)
18,533 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Flip Flop 2 Element JK Type 1 Bit Positive Edge 16-CDIP (0.300", 7.62mm)
CD54AC109F3A
| Category | Integrated Circuits (ICs) - Logic - Flip Flops |
| Manufacturer | Texas Instruments |
| Series | 54AC |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Function | Set(Preset) and Reset |
| Type | JK Type |
| Output Type | Complementary |
| Number of Elements | 2 |
| Number of Bits per Element | 1 |
| Clock Frequency | 100 MHz |
| Max Propagation Delay @ V, Max CL | 10.3ns @ 5V, 50pF |
| Trigger Type | Positive Edge |
| Current - Output High, Low | 24mA, 24mA |
| Voltage - Supply | 1.5V ~ 5.5V |
| Current - Quiescent (Iq) | 4 µA |
| Input Capacitance | 10 pF |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Supplier Device Package | 16-CDIP |
| Package / Case | 16-CDIP (0.300", 7.62mm) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | CD54AC112F3A | CD54AC112F3A | CD54AC273F3A | CD54AC74F3A |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | CD54AC112 DUAL NEGATIVE EDGE TRI | DUAL NEGATIVE EDGE TRIGGERED J-K | OCTAL D-TYPE FLIP-FLOPS WITH RES | DUAL POSITIVE-EDGE-TRIGGERED D-T |
| Series | * | 54AC | 54AC | 54AC |
| Packaging | Bulk | Tube | Tube | Tube |
