CD54HC7046AF
lmages are for reference only.CD54HC7046AF
IC PHASE LOCK LOOP 16CERDIP
Datasheet16-CDIP (0.300", 7.62mm)
57,328 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Phase Lock Loop (PLL) IC 400kHz 1 16-CDIP (0.300", 7.62mm)
CD54HC7046AF
| Category | Integrated Circuits (ICs) - Clock-Timing - Clock Generators-PLLs-Frequency Synthesizers |
| Manufacturer | Harris Corporation |
| Series | 54HC |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Base Product Number | - |
| Type | Phase Lock Loop (PLL) |
| PLL | Yes |
| Input | CMOS |
| Output | CMOS |
| Number of Circuits | 1 |
| Ratio - Input:Output | 4:4 |
| Differential - Input:Output | No/No |
| Frequency - Max | 400kHz |
| Divider/Multiplier | No/No |
| Voltage - Supply | 2V ~ 6V |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 16-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 16-CERDIP |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | CD54HC4046AF | CD54HC4046AF3A | CD54HCT4046AF3A | CD54HCT7046AF |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Harris Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | HIGH SPEED CMOS LOGIC PHASE-LOCK | HIGH SPEED CMOS LOGIC PHASE-LOCK | HIGH SPEED CMOS LOGIC PHASE-LOCK | IC PHASE LOCK LOOP 16CERDIP |
| Series | 54HC | 54HC | 54HCT | 54HCT |
| Packaging | Tube | Tube | Tube | Bulk |
