CD74HC20M
lmages are for reference only.CD74HC20M
IC GATE NAND 2CH 4-INP 14SOIC
Datasheet14-SOIC (0.154", 3.90mm Width)
25,828 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
NAND Gate IC 2 Channel 14-SOIC
CD74HC20M
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | Harris Corporation |
| Series | 74HC |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| Base Product Number | 74HC20 |
| Logic Type | NAND Gate |
| Number of Circuits | 2 |
| Number of Inputs | 4 |
| Features | - |
| Voltage - Supply | 2V ~ 6V |
| Current - Quiescent (Max) | 2 μA |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Input Logic Level - Low | 0.5V ~ 1.8V |
| Input Logic Level - High | 1.5V ~ 4.2V |
| Max Propagation Delay @ V, Max CL | 17ns @ 6V, 50pF |
| Operating Temperature | -55＜C ~ 125＜C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-SOIC |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | CD74HC20E | CD74HC20E | CD74HC20M | CD74HC20M96 |
| Manufacturer | Texas Instruments | Harris Corporation | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC GATE NAND 2CH 4-INP 14DIP | IC GATE NAND 2CH 4-INP 14DIP | IC GATE NAND 2CH 4-INP 14SOIC | IC GATE NAND 2CH 4-INP 14SOIC |
| Series | 74HC | 74HC | 74HC | 74HC |
| Packaging | Tube | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
