Product CatalogPart Number
CED1A102MCB10A5
Manufacturer
Chinsan (Elite)Description
CAP ALUM 1000UF 20% 10V SMD
Datasheet
DatasheetPackage
Radial, Can - SMD
In Stock
71,139 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CED1A102MCB10A5
CED1A102MCB10A5
lmages are for reference only.Payment Methods
Delivery Services
1000 µF 10 V Aluminum Electrolytic Capacitors Radial, Can - SMD 3000 Hrs @ 105°C
Quick Inquiry
CED1A102MCB10A5
Specifications
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | Chinsan (Elite) |
| Series | CED |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 1000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 10 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 268 mA @ 120 Hz |
| Ripple Current @ High Frequency | 670 mA @ 100 kHz |
| Lead Spacing | - |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.433" (11.00mm) |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Base Product Number | - |
| Impedance | 90 mOhms |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | CED1A151MCB6358 | CED1A221MCB6377 | 25YXM100MEFR6.3X11 | 16PX100MEFCTA5X11 |
| Manufacturer | Chinsan (Elite) | Chinsan (Elite) | Rubycon | Rubycon |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP ALUM 150UF 20% 10V SMD | CAP ALUM 220UF 20% 10V SMD | CAP ALUM 100UF 20% 25V RADIAL TH | CAP ALUM 100UF 20% 16V RADIAL TH |
| Series | Chinsan (Elite) | Chinsan (Elite) | Rubycon | Rubycon |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Cut Tape (CT)-->Tape & Box (TB) |
