CH02016-100RGFTA
lmages are for reference only.CH02016-100RGFTA
CH 02016 100U 2% F TR100 E2
Datasheet02016 (0504 Metric)
90,361 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
100 Ohms ±2% 0.03W, 1/32W Chip Resistor 02016 (0504 Metric) RF, High Frequency Thin Film
CH02016-100RGFTA
| Category | Resistors - Chip Resistor Surface Mount - |
| Manufacturer | Vishay Sfernice |
| Series | CH |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Resistance | 100 Ohms |
| Tolerance | ±2% |
| Power (Watts) | 0.03W, 1/32W |
| Composition | Thin Film |
| Features | RF, High Frequency |
| Temperature Coefficient | ±100ppm/°C |
| Operating Temperature | -55°C ~ 155°C |
| Package / Case | 02016 (0504 Metric) |
| Supplier Device Package | 02016 |
| Ratings | - |
| Size / Dimension | 0.019" L x 0.015" W (0.48mm x 0.39mm) |
| Height - Seated (Max) | 0.022" (0.55mm) |
| Number of Terminations | 2 |
| Failure Rate | - |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | CH02016-100RGFTB | CH02016-100RGFTD | CH02016-100RGFW | CH02016-100RGPT |
| Manufacturer | Vishay Sfernice | Vishay Sfernice | Vishay Sfernice | Vishay Sfernice |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | CH 02016 100U 2% F TR250 E2 | RES CH 02016 THIN FILM | RES CH 02016 THIN FILM | RES CH 02016 THIN FILM |
| Series | Vishay Sfernice | |||
| Packaging | Tape & Reel (TR) |
