Product CatalogPart Number
CM150DX-24A
Manufacturer
Powerex Inc.Description
IGBT MOD 1200V 150A 960W
Datasheet
DatasheetPackage
Module
In Stock
44,230 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CM150DX-24A
CM150DX-24A
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module Half Bridge 1200 V 150 A 960 W Chassis Mount Module
Quick Inquiry
CM150DX-24A
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Powerex Inc. |
| Series | IGBTMOD™ |
| Packaging | Bulk |
| RoHS Status | |
| IGBT Type | - |
| Configuration | Half Bridge |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 150 A |
| Power - Max | 960 W |
| Vce(on) (Max) @ Vge, Ic | 2.6V @ 15V, 150A |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 23 nF @ 10 V |
| Input | Standard |
| NTC Thermistor | Yes |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | Module |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
|
 |
 |
| Part Number | CM150RL-12NF | CM150RL-24NF | CM150RX-24S1 | CPV364M4F |
| Manufacturer | Powerex Inc. | Powerex Inc. | Powerex Inc. | Vishay General Semiconductor - Diodes Division |
| RoHS Status | RoHS Compliant | RoHS non-compliant | ||
| Description | IGBT MOD 600V 150A 730W | IGBT MOD 1200V 150A 890W | IGBT MOD 1200V 150A 935W | IGBT MODULE 600V 27A 63W IMS-2 |
| Series | IGBTMOD™ | IGBTMOD™ | - | - |
| Packaging | Bulk | Bulk | Bulk |
