Product CatalogPart Number
CM300DX-12A
Manufacturer
Powerex Inc.Description
IGBT MOD 600V 300A 960W
Datasheet
DatasheetPackage
Module
In Stock
56,506 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CM300DX-12A
CM300DX-12A
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module Half Bridge 600 V 300 A 960 W Chassis Mount Module
Quick Inquiry
CM300DX-12A
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Powerex Inc. |
| Series | IGBTMOD™ |
| Packaging | Bulk |
| RoHS Status | |
| IGBT Type | - |
| Configuration | Half Bridge |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 300 A |
| Power - Max | 960 W |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 300A |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 34 nF @ 10 V |
| Input | Standard |
| NTC Thermistor | Yes |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | Module |
| Base Product Number | - |
