CM5022R151R-10
lmages are for reference only.CM5022R151R-10
CMC 5A 8LN 150 OHM SMD
DatasheetVertical, 18 Flat Lead
67,760 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
8 Line Common Mode Choke Surface Mount 150 Ohms @ 100 MHz 5A DCR 20mOhm
CM5022R151R-10
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Laird-Signal Integrity Products |
| Series | CM |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 8 |
| Inductance @ Frequency | - |
| Current Rating (Max) | 5A |
| DC Resistance (DCR) (Max) | 20mOhm |
| Voltage Rating - DC | - |
| Voltage Rating - AC | - |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Surface Mount |
| Size / Dimension | 0.495" L x 0.265" W (12.57mm x 6.73mm) |
| Height (Max) | 0.331" (8.40mm) |
| Package / Case | Vertical, 18 Flat Lead |
| Base Product Number | - |
| Impedance @ Frequency | 150 Ohms @ 100 MHz |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | CM5022R151R-00 | CM5022R201R-00 | CM5022R201R-10 | CM5022R800R-00 |
| Manufacturer | Laird-Signal Integrity Products | Laird-Signal Integrity Products | Laird-Signal Integrity Products | Laird-Signal Integrity Products |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | CMC 5A 8LN 150 OHM SMD | CMC 5A 8LN 200 OHM SMD | CMC 5A 8LN 200 OHM SMD | CMC 5A 8LN 80 OHM SMD |
| Series | CM | CM | CM | CM |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
