CMDA5AR7D1S
lmages are for reference only.CMDA5AR7D1S
LED RED DIFFUSED 0805 SMD
Datasheet0805 (2012 Metric)
73,292 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Red LED Indication - Discrete 1.9V 0805 (2012 Metric)
CMDA5AR7D1S
| Category | Optoelectronics - LED Indication Discrete - |
| Manufacturer | Visual Communications Company - VCC |
| Series | CMDA5 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Color | Red |
| Configuration | Standard |
| Lens Color | - |
| Lens Transparency | Diffused |
| Millicandela Rating | 90mcd |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 1.40mm x 1.25mm |
| Voltage - Forward (Vf) (Typ) | 1.9V |
| Current - Test | 20mA |
| Viewing Angle | 170° |
| Mounting Type | Surface Mount |
| Wavelength - Dominant | - |
| Wavelength - Peak | 637nm |
| Features | - |
| Package / Case | 0805 (2012 Metric) |
| Supplier Device Package | 0805 |
| Size / Dimension | 2.00mm L x 1.25mm W |
| Height (Max) | 0.80mm |
| Base Product Number | CMDA5AR7 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | CMDA5AA7D1S | CMDA5AG7D1S | CMDA5AY7D1S | CMDA5AY7D1Z |
| Manufacturer | Visual Communications Company - VCC | Visual Communications Company - VCC | Visual Communications Company - VCC | Visual Communications Company - VCC |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LED ORANGE DIFFUSED 0805 SMD | LED GREEN DIFFUSED 0805 SMD | LED GREEN DIFFUSED 0805 SMD | LED YELLOW DIFFUSED SMD R/A |
| Series | Visual Communications Company - VCC | Visual Communications Company - VCC | Visual Communications Company - VCC | Visual Communications Company - VCC |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
