CMF16-393800-B
Manufacturer
Triad MagneticsDescription
CMC 39MH 800MA 2LN TH
Datasheet
DatasheetPackage
Vertical, 4 PC Pin
In Stock
29,836 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CMF16-393800-B
CMF16-393800-B
lmages are for reference only.Payment Methods
Delivery Services
39 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 800mA DCR 1.21Ohm
Quick Inquiry
CMF16-393800-B
Specifications
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Triad Magnetics |
| Series | CMF |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 39 mH @ 10 kHz |
| Current Rating (Max) | 800mA |
| DC Resistance (DCR) (Max) | 1.21Ohm |
| Voltage Rating - DC | - |
| Voltage Rating - AC | 300V |
| Operating Temperature | -40°C ~ 105°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.965" L x 0.571" W (24.50mm x 14.50mm) |
| Height (Max) | 0.531" (13.50mm) |
| Package / Case | Vertical, 4 PC Pin |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
