CQ320A
lmages are for reference only.CQ320A
CORELESS CURENT SENSOR / 20A W/S
Datasheet24-LSSOP (0.220", 5.60mm Width), 10 Leads
77,175 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Current Sensor 29.3A 1 Channel Hall Effect, Open Loop Bidirectional 24-LSSOP (0.220", 5.60mm Width), 10 Leads
CQ320A
| Category | Sensors, Transducers - Current Sensors - |
| Manufacturer | Asahi Kasei Microdevices/AKM |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| For Measuring | AC/DC |
| Sensor Type | Hall Effect, Open Loop |
| Current - Sensing | 29.3A |
| Number of Channels | 1 |
| Output | Ratiometric, Voltage |
| Sensitivity | 45mV/A |
| Frequency | - |
| Linearity | - |
| Accuracy | ±1.3% |
| Voltage - Supply | 3.3V |
| Response Time | 0.5µs |
| Current - Supply (Max) | 6.2mA |
| Operating Temperature | -40°C ~ 90°C |
| Polarization | Bidirectional |
| Mounting Type | Surface Mount |
| Package / Case | 24-LSSOP (0.220", 5.60mm Width), 10 Leads |
| Supplier Device Package | 24-VSOP |
| Base Product Number | CQ320 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | CQ3200 | CQ3201 | CQ3202 | CQ3203 |
| Manufacturer | Asahi Kasei Microdevices/AKM | Asahi Kasei Microdevices/AKM | Asahi Kasei Microdevices/AKM | Asahi Kasei Microdevices/AKM |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CORELESS CURENT SENSOR / 20A W/S | CORELESS CURENT SENSOR / 20A W/S | CORELESS CURENT SENSOR / 20A W/S | CORELESS CURENT SENSOR / 20A W/S |
| Series | Asahi Kasei Microdevices/AKM | Asahi Kasei Microdevices/AKM | Asahi Kasei Microdevices/AKM | Asahi Kasei Microdevices/AKM |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
