CS5503 - 20-BIT A/D CONVERTER
Datasheet20-SOIC (0.295", 7.50mm Width)
65,159 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
20 Bit Analog to Digital Converter 1 Input 1 Sigma-Delta 20-SOIC
CS5503-BS
| Category | Integrated Circuits (ICs) - Data Acquisition - Analog to Digital Converters ADC |
| Manufacturer | Cirrus Logic Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Number of Bits | 20 |
| Sampling Rate (Per Second) | - |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | Serial |
| Configuration | ADC |
| Ratio - S/H:ADC | 0:1 |
| Number of A/D Converters | 1 |
| Architecture | Sigma-Delta |
| Reference Type | External |
| Voltage - Supply, Analog | 4.5V ~ 5.5V |
| Voltage - Supply, Digital | 4.5V ~ 5.5V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 20-SOIC |
| Mounting Type | Surface Mount |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | CS5012A-BL7Z | CS5014-BL14Z | CS5016-AP16 | CS5016-BL16 |
| Manufacturer | Cirrus Logic Inc. | Cirrus Logic Inc. | Cirrus Logic Inc. | Cirrus Logic Inc. |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ||
| Description | IC ADC 12BIT SAR 44PLCC | IC ADC 14BIT SAR 44PLCC | 16-BIT, SELF-CALIBRATING ADC | IC ADC 16BIT SAR 44PLCC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Bulk | Tray |
