Product CatalogPart Number
CSD95377Q4M
Manufacturer
Texas InstrumentsDescription
IC HALF BRIDGE DRIVER 30A 8VSON
Datasheet
DatasheetPackage
8-PowerVFDFN
In Stock
75,676 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CSD95377Q4M
CSD95377Q4M
lmages are for reference only.Payment Methods
Delivery Services
Half Bridge Driver Synchronous Buck Converters Power MOSFET 8-VSON (3.5x4.5)
Quick Inquiry
CSD95377Q4M
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Full Half-Bridge H Bridge Drivers |
| Manufacturer | Texas Instruments |
| Series | NexFET™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Half Bridge |
| Applications | Synchronous Buck Converters |
| Interface | PWM |
| Load Type | Inductive |
| Technology | Power MOSFET |
| Rds On (Typ) | - |
| Current - Output / Channel | 30A |
| Current - Peak Output | 70A |
| Voltage - Supply | 4.5V ~ 5.5V |
| Voltage - Load | 16V (Max) |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Features | Bootstrap Circuit, Diode Emulation |
| Fault Protection | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerVFDFN |
| Supplier Device Package | 8-VSON (3.5x4.5) |
| Base Product Number | CSD95377 |
| Grade | - |
| Qualification | - |
