CTX10-3-R
lmages are for reference only.CTX10-3-R
INDUCT ARRAY 2 COIL 9.6UH SMD
DatasheetNonstandard
56,973 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Unshielded 2 Coil Inductor Array 38.4 µH Inductance - Connected in Series 9.6 µH Inductance - Connected in Parallel 28mOhm Max DC Resistance (DCR) - Parallel 2.7 A Nonstandard
CTX10-3-R
| Category | Inductors, Coils, Chokes - Arrays-Signal Transformers - |
| Manufacturer | Eaton - Electronics Division |
| Series | OCTA-PAC® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Number of Coils | 2 |
| Inductance - Connected In Parallel | 9.6 µH |
| Inductance - Connected In Series | 38.4 µH |
| Tolerance | ±20% |
| Current Rating - Parallel | 2.7 A |
| Current Rating - Series | 1.35 A |
| Current Saturation - Parallel | - |
| Current Saturation - Series | - |
| DC Resistance (DCR) - Parallel | 28mOhm Max |
| DC Resistance (DCR) - Series | 111mOhm Max |
| Shielding | Unshielded |
| Ratings | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Size / Dimension | 0.550" L x 0.550" W (13.97mm x 13.97mm) |
| Height | 0.190" (4.83mm) |
| Base Product Number | - |
| Product Attribute | |
 |
|
 |
| Part Number | CTX10-3-R | CTX10-1-R | CTX10-1-R | CTX10-1A-R |
| Manufacturer | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | INDUCT ARRAY 2 COIL 9.6UH SMD | INDUCT ARRAY 2 COIL 10UH SMD | INDUCT ARRAY 2 COIL 10UH SMD | INDUCT ARRAY 2 COIL 10.58UH SMD |
| Series | OCTA-PAC® | OCTA-PAC® | OCTA-PAC® | OCTA-PAC® PLUS |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
