CTX5-1P-R
lmages are for reference only.CTX5-1P-R
INDUCT ARRAY 2 COIL 4.83UH SMD
DatasheetNonstandard
85,678 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Unshielded 2 Coil Inductor Array 19.31 µH Inductance - Connected in Series 4.83 µH Inductance - Connected in Parallel 40mOhm Max DC Resistance (DCR) - Parallel 2 A Nonstandard
CTX5-1P-R
| Category | Inductors, Coils, Chokes - Arrays-Signal Transformers - |
| Manufacturer | Eaton - Electronics Division |
| Series | Econo-Pac™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Number of Coils | 2 |
| Inductance - Connected In Parallel | 4.83 µH |
| Inductance - Connected In Series | 19.31 µH |
| Tolerance | ±20% |
| Current Rating - Parallel | 2 A |
| Current Rating - Series | 1 A |
| Current Saturation - Parallel | - |
| Current Saturation - Series | - |
| DC Resistance (DCR) - Parallel | 40mOhm Max |
| DC Resistance (DCR) - Series | 161mOhm Max |
| Shielding | Unshielded |
| Ratings | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Size / Dimension | 0.450" L x 0.450" W (11.43mm x 11.43mm) |
| Height | 0.165" (4.19mm) |
| Base Product Number | - |
| Product Attribute | |
 |
|
 |
| Part Number | CTX5-1P-R | CTX5-1-R | CTX5-1-R | CTX5-1A-R |
| Manufacturer | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | INDUCT ARRAY 2 COIL 4.83UH SMD | INDUCT ARRAY 2 COIL 4.9UH SMD | INDUCT ARRAY 2 COIL 4.9UH SMD | INDUCT ARRAY 2 COIL 4.7UH SMD |
| Series | Econo-Pac™ | OCTA-PAC® | OCTA-PAC® | OCTA-PAC® PLUS |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
