D1WEL0805CR301F-T5
lmages are for reference only.D1WEL0805CR301F-T5
RES 0.301 OHM 1% 3/4W 0805
Datasheet0805 (2012 Metric)
60,834 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
301 mOhms ±1% 0.75W, 3/4W Chip Resistor 0805 (2012 Metric) Anti-Sulfur, Current Sense, Flame Retardant Coating, Moisture Resistant, Safety Metal Foil
D1WEL0805CR301F-T5
| Category | Resistors - Chip Resistor Surface Mount - |
| Manufacturer | Thin Film Technology Corp. |
| Series | D1WEL |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Resistance | 301 mOhms |
| Tolerance | ±1% |
| Power (Watts) | 0.75W, 3/4W |
| Composition | Metal Foil |
| Features | Anti-Sulfur, Current Sense, Flame Retardant Coating, Moisture Resistant, Safety |
| Temperature Coefficient | ±50ppm/°C |
| Operating Temperature | -55°C ~ 155°C |
| Package / Case | 0805 (2012 Metric) |
| Supplier Device Package | 0805 |
| Ratings | - |
| Size / Dimension | 0.083" L x 0.053" W (2.11mm x 1.35mm) |
| Height - Seated (Max) | 0.033" (0.85mm) |
| Number of Terminations | 2 |
| Failure Rate | - |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | D1WEL0805CR300F-T5 | D1WEL0805CR330F-T5 | D1WEL0805CR050F-T5 | D1WEL0805CR068F-T5 |
| Manufacturer | Thin Film Technology Corp. | Thin Film Technology Corp. | Thin Film Technology Corp. | Thin Film Technology Corp. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RES 0.3 OHM 1% 3/4W 0805 | RES 0.33 OHM 1% 3/4W 0805 | RES 0.05 OHM 1% 3/4W 0805 | RES 0.068 OHM 1% 3/4W 0805 |
| Series | Thin Film Technology Corp. | Thin Film Technology Corp. | Thin Film Technology Corp. | |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
