DBL206G-T
lmages are for reference only.DBL206G-T
2A, 800V, STANDARD BRIDGE RECTIF
Datasheet4-DIP (0.300", 7.62mm)
56,992 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bridge Rectifier Single Phase Standard 800 V Through Hole DBL
DBL206G-T
| Category | Discrete Semiconductor Products - Diodes - Bridge Rectifiers |
| Manufacturer | Taiwan Semiconductor Corporation |
| Series | - |
| Packaging | Tube |
| RoHS Status | |
| Diode Type | Single Phase |
| Technology | Standard |
| Voltage - Peak Reverse (Max) | 800 V |
| Current - Average Rectified (Io) | 2 A |
| Voltage - Forward (Vf) (Max) @ If | 1.15 V @ 2 A |
| Current - Reverse Leakage @ Vr | 2 µA @ 800 V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | 4-DIP (0.300", 7.62mm) |
| Supplier Device Package | DBL |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
|
| Part Number | DBL206G | DBL206GH | DBL101G | DBL101G C1G |
| Manufacturer | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | BRIDGE RECT 1PHASE 800V 2A DBL | BRIDGE RECT 1PHASE 800V 2A DBL | DIODE BRIDGE 1A 50V DBL | BRIDGE RECT 1PHASE 50V 1A DBL |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
