DBLS206GH
lmages are for reference only.DBLS206GH
BRIDGE RECT 1PHASE 800V 2A DBLS
Datasheet4-SMD, Gull Wing
13,562 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bridge Rectifier Single Phase Standard 800 V Surface Mount DBLS
DBLS206GH
| Category | Discrete Semiconductor Products - Diodes - Bridge Rectifiers |
| Manufacturer | Taiwan Semiconductor Corporation |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Diode Type | Single Phase |
| Technology | Standard |
| Voltage - Peak Reverse (Max) | 800 V |
| Current - Average Rectified (Io) | 2 A |
| Voltage - Forward (Vf) (Max) @ If | 1.15 V @ 2 A |
| Current - Reverse Leakage @ Vr | 2 µA @ 800 V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, Gull Wing |
| Supplier Device Package | DBLS |
| Base Product Number | DBLS206 |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
 |
 |
 |
| Part Number | DBLS206G | DBLS206G-T | DBLS201G | DBLS201G C1G |
| Manufacturer | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | BRIDGE RECT 1PHASE 800V 2A DBLS | 2A, 800V, STANDARD BRIDGE RECTIF | 2A, 50V, STANDARD BRIDGE RECTIFI | BRIDGE RECT 1PHASE 50V 2A DBLS |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) | Tube |
