DCM181713H-701NHF
lmages are for reference only.DCM181713H-701NHF
700uH, 27mOhm, 5Amp Max. DIP CMC
DatasheetHorizontal, 4 PC Pin
62,027 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
700 µH @ 10 kHz 2 Line Common Mode Choke Through Hole 5A DCR 27mOhm
DCM181713H-701NHF
| Category | Filters - Common Mode Chokes - |
| Manufacturer | ITG Electronics, Inc. |
| Series | DCM181713H |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 700 µH @ 10 kHz |
| Current Rating (Max) | 5A |
| DC Resistance (DCR) (Max) | 27mOhm |
| Voltage Rating - DC | - |
| Voltage Rating - AC | - |
| Operating Temperature | -55°C ~ 130°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.709" L x 0.689" W (18.00mm x 17.50mm) |
| Height (Max) | 0.512" (13.00mm) |
| Package / Case | Horizontal, 4 PC Pin |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | DCM181713H-102NHF | DCM181713H-103NHF | DCM181713H-153NHF | DCM181713H-222NHF |
| Manufacturer | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | 1,000uH, 55mOhm, 2.5Amp DIP CMC | 10,000uH,500mOhm,0.7Amp DIP CMC | 15,000uH,780mOhm,0.5Amp DIP CMC | 2,200uH, 90mOhm, 2 Amp DIP CMC |
| Series | DCM181713H | DCM181713H | DCM181713H | DCM181713H |
| Packaging | Bulk | Bulk | Bulk | Bulk |
