DCM232315H-332NHF
lmages are for reference only.DCM232315H-332NHF
3,300uH, 120mOhm, 2Amp DIP CMC
DatasheetHorizontal, 4 PC Pin
15,086 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
3.3 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 2A DCR 120mOhm
DCM232315H-332NHF
| Category | Filters - Common Mode Chokes - |
| Manufacturer | ITG Electronics, Inc. |
| Series | DCM232315H |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 3.3 mH @ 10 kHz |
| Current Rating (Max) | 2A |
| DC Resistance (DCR) (Max) | 120mOhm |
| Voltage Rating - DC | - |
| Voltage Rating - AC | - |
| Operating Temperature | -55°C ~ 130°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.906" L x 0.906" W (23.00mm x 23.00mm) |
| Height (Max) | 0.610" (15.50mm) |
| Package / Case | Horizontal, 4 PC Pin |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | DCM232315H-102NHF | DCM232315H-103NHF | DCM232315H-203NHF | DCM232315H-222NHF |
| Manufacturer | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | 1,000uH, 35mOhm, 5Amp DIP CMC | 10,000uH,260mOhm, 1.5Amp DIP CMC | 20,000uH,520mOhm, 0.7Amp DIP CMC | 2,200uH, 65mOhm, 3Amp DIP CMC |
| Series | DCM232315H | DCM232315H | DCM232315H | DCM232315H |
| Packaging | Bulk | Bulk | Bulk | Bulk |
