DCM282818H-502NHF
lmages are for reference only.DCM282818H-502NHF
5,000uH,85mOhm,4Amp Max. DIP CMC
DatasheetHorizontal, 4 PC Pin
43,243 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
5 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 4A DCR 85mOhm
DCM282818H-502NHF
| Category | Filters - Common Mode Chokes - |
| Manufacturer | ITG Electronics, Inc. |
| Series | DCM282818H |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 5 mH @ 10 kHz |
| Current Rating (Max) | 4A |
| DC Resistance (DCR) (Max) | 85mOhm |
| Voltage Rating - DC | - |
| Voltage Rating - AC | - |
| Operating Temperature | -55°C ~ 130°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 1.102" L x 1.102" W (28.00mm x 28.00mm) |
| Height (Max) | 0.709" (18.00mm) |
| Package / Case | Horizontal, 4 PC Pin |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | DCM282818H-103NHF | DCM282818H-203NHF | DCM282818H-222NHF | DCM282818H-253NHF |
| Manufacturer | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | 10,000uH,170mOhm, 2.5Amp DIP CMC | 20,000uH, 300mOhm, 2Amp DIP CMC | 2,200uH,34mOhm,6Amp Max. DIP CMC | 25,000uH,430mOhm, 1.5Amp DIP CMC |
| Series | DCM282818H | DCM282818H | DCM282818H | DCM282818H |
| Packaging | Bulk | Bulk | Bulk | Bulk |
