DCN181320V1-102HF
lmages are for reference only.DCN181320V1-102HF
1,000uH, 16mOhm, 5.4Amp DIP CMC
DatasheetVertical, 4 PC Pin
50,376 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 5.4A DCR 16mOhm
DCN181320V1-102HF
| Category | Filters - Common Mode Chokes - |
| Manufacturer | ITG Electronics, Inc. |
| Series | DCN181320V |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 1 mH @ 10 kHz |
| Current Rating (Max) | 5.4A |
| DC Resistance (DCR) (Max) | 16mOhm |
| Voltage Rating - DC | - |
| Voltage Rating - AC | 250V |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.728" L x 0.531" W (18.50mm x 13.50mm) |
| Height (Max) | 0.807" (20.50mm) |
| Package / Case | Vertical, 4 PC Pin |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | DCN181320V1-103HF | DCN181320V1-153HF | DCN181320V1-222HF | DCN181320V1-273HF |
| Manufacturer | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | 10,000uH,120mOhm, 1.4Amp DIP CMC | 15,000uH,210mOhm, 1.2Amp DIP CMC | 2,200uH,33mOhm, 3.5Amp DIP CMC | 27,000uH,410mOhm, 1.1Amp DIP CMC |
| Series | DCN181320V | DCN181320V | DCN181320V | DCN181320V |
| Packaging | Bulk | Bulk | Bulk | Bulk |
