DF17A(4.0)-20DP-0.5V(57)
lmages are for reference only.DF17A(4.0)-20DP-0.5V(57)
CONN HEADER 20POS .5MM SMD GOLD
Datasheet-
18,489 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
20 Position Connector Header, Outer Shroud Contacts Surface Mount Gold
DF17A(4.0)-20DP-0.5V(57)
| Category | Connectors, Interconnects - Rectangular Connectors - Arrays-Edge Type-Mezzanine Board to Board |
| Manufacturer | Hirose Electric Co Ltd |
| Series | DF17 |
| Packaging | Cut Tape (CT) |
| RoHS Status | RoHS Compliant |
| Connector Type | Header, Outer Shroud Contacts |
| Number of Positions | 20 |
| Pitch | 0.020" (0.50mm) |
| Number of Rows | 2 |
| Mounting Type | Surface Mount |
| Features | Board Guide |
| Contact Finish | Gold |
| Contact Finish Thickness | - |
| Mated Stacking Heights | 7mm, 8mm |
| Height Above Board | 0.248" (6.30mm) |
| Base Product Number | DF17A(4.0) |
| Product Attribute | -20DP-0.5V(51).jpg "DF17A(4.0)-20DP-0.5V(51)") |
-20DS-0.5V(57).jpg "DF17A(4.0)-20DS-0.5V(57)") |
-30DS-0.5V(57).jpg "DF17A(4.0)-30DS-0.5V(57)") |
-40DP-0.5V(51).jpg "DF17A(4.0)-40DP-0.5V(51)") |
| Part Number | DF17A(4.0)-20DP-0.5V(51) | DF17A(4.0)-20DS-0.5V(57) | DF17A(4.0)-30DS-0.5V(57) | DF17A(4.0)-40DP-0.5V(51) |
| Manufacturer | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ||
| Description | CONN HDR 20POS SMD GOLD | CONN RCPT 20POS SMD GOLD | CONN RCPT 30POS SMD GOLD | CONN HDR 40POS SMD GOLD |
| Series | DF17 | DF17 | DF17 | DF17 |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
