DF2CN20
lmages are for reference only.DF2CN20
TERMINAL BLOCK FUSE 500VAC 20AMP
Datasheet5AG, 10mm x 38.1mm
70,969 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
20A 500 VAC Fuse Cartridge Requires Holder
DF2CN20
| Category | Circuit Protection - Electrical-Specialty Fuses - |
| Manufacturer | Schneider Electric |
| Series | DF2 |
| Packaging | Box |
| RoHS Status | RoHS non-compliant |
| Mounting Type | Requires Holder |
| Fuse Type | Cartridge |
| Current Rating (Amps) | 20A |
| Voltage Rating - AC | 500 VAC |
| Response Time | - |
| Applications | Electrical, Industrial |
| Features | - |
| Class | - |
| Approval Agency | - |
| Operating Temperature | - |
| Breaking Capacity @ Rated Voltage | - |
| Package / Case | 5AG, 10mm x 38.1mm |
| Size / Dimension | 0.394" Dia x 1.496" L (10.00mm x 38.00mm) |
| Base Product Number | - |
| Voltage Rating - DC | - |
| Grade | - |
| Qualification | - |
| Melting I²t | - |
| DC Cold Resistance | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | DF2CA01 | DF2CA02 | DF2CA04 | DF2CA06 |
| Manufacturer | Schneider Electric | Schneider Electric | Schneider Electric | Schneider Electric |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | TERMINAL BLOCKS FUSE 500VAC 1AMP | TERMINAL BLOCKS FUSE 500VAC 2AMP | TERMINAL BLOCKS FUSE 500VAC 4AMP | TERMINAL BLOCKS FUSE 500VAC 6AMP |
| Series | DF2 | DF2 | DF2 | DF2 |
| Packaging | Box | Box | Box | Box |
