DLC-L20D-D4
lmages are for reference only.DLC-L20D-D4
SENSOR 0.72PSID 0.12" 16BIT
Datasheet16-SOIC Module, Dual Top Ports
96,107 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Pressure Sensor ±0.72PSI (±4.98kPa) Differential Male - 0.12" (3mm) Tube, Dual 16 b 16-SOIC Module, Dual Top Ports
DLC-L20D-D4
| Category | Sensors, Transducers - Pressure Sensors-Transducers - |
| Manufacturer | Amphenol All Sensors Corporation |
| Series | DLC |
| Packaging | Tube |
| RoHS Status | RoHS Compliant |
| Base Product Number | DLC-L20D |
| Applications | Board Mount |
| Pressure Type | Differential |
| Operating Pressure | ±0.72PSI (±4.98kPa) |
| Output Type | I2C |
| Output | 16 b |
| Accuracy | ±1% |
| Voltage - Supply | 1.8V ~ 3.6V |
| Port Size | Male - 0.12" (3mm) Tube, Dual |
| Port Style | Barbed |
| Features | Temperature Compensated |
| Termination Style | Gull Wing |
| Maximum Pressure | 7.25PSI (50kPa) |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC Module, Dual Top Ports |
| Supplier Device Package | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | DLC-L20D-D4 | DLC-L01D-D4 | DLC-L01G-U2 | DLC-L05D-D4 |
| Manufacturer | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation | Amphenol All Sensors Corporation |
| RoHS Status | RoHS Compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant |
| Description | SENSOR 0.72PSID 0.12" 16BIT | SENSOR 0.04PSID 0.12" 16BIT | SENSOR 0.04PSIG 0.12" 16BIT | SENSOR 0.18PSID 0.12" 16BIT |
| Series | DLC | DLC | DLC | DLC |
| Packaging | Tube | Tube | Tube | Tube |
