DM0412LW2
lmages are for reference only.DM0412LW2
HIGH ISOLATION, DOUBLE BALANCED
DatasheetModule, SMA Connectors
74,248 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Mixer IC General Purpose Up/Down Converter 4GHz ~ 16GHz Module
DM0412LW2
| Category | RF and Wireless - RF Mixers - |
| Manufacturer | L3 Narda-MITEQ |
| Series | - |
| Packaging | Box |
| RoHS Status | RoHS Compliant |
| RF Type | General Purpose |
| Frequency | 4GHz ~ 16GHz |
| Number of Mixers | 2 |
| Gain | - |
| Noise Figure | 9dB |
| Secondary Attributes | Up/Down Converter |
| Current - Supply | - |
| Voltage - Supply | - |
| Mounting Type | Connector Mount |
| Package / Case | Module, SMA Connectors |
| Supplier Device Package | Module |
| Base Product Number | DM0412 |
| Product Attribute |  |
 |
 |
 |
| Part Number | DM0052LA2 | DM0104LA1 | DM0208LW2 | DM0416LA1 |
| Manufacturer | L3 Narda-MITEQ | L3 Narda-MITEQ | L3 Narda-MITEQ | L3 Narda-MITEQ |
| RoHS Status | Not applicable | Not applicable | Not applicable | |
| Description | HIGH ISOLATION DOUBLE BALANCED | HIGH ISOLATION DOUBLE BALANCED | HIGH ISOLATION DOUBLE BALANCED | DOUBLE BALANCED MIXER - HIGH ISO |
| Series | - | DM0104L | DM | DM |
| Packaging | Box | Box | Box | Box |
