DMC3021LK4-13
lmages are for reference only.DMC3021LK4-13
MOSFET N/P-CH 30V 9.4A TO252-4L
DatasheetTO-252-5, DPAK (4 Leads + Tab), TO-252AD
47,423 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Mosfet Array 30V 9.4A, 6.8A 2.7W Surface Mount TO-252-4L
DMC3021LK4-13
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | N and P-Channel, Common Drain |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 9.4A, 6.8A |
| Rds On (Max) @ Id, Vgs | 21mOhm @ 7A, 10V |
| Vgs(th) (Max) @ Id | 2.1V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 17.4nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 751pF @ 10V |
| Power - Max | 2.7W |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-5, DPAK (4 Leads + Tab), TO-252AD |
| Supplier Device Package | TO-252-4L |
| Base Product Number | DMC3021 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | DMC3021LSD-13 | DMC3021LSDQ-13 | DMC1015UPD-13 | DMC1016UPD-13 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N/P-CH 30V 8.5A/7A 8SO | MOSFET N/P-CH 30V 8.5A/7A 8SO | MOSFET N/P-CH 12V 9.5A PWRDI50 | MOSFET N/P-CH 12V 9.5A PWRDI50 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
