Product CatalogPart Number
DME-04-S2-S
Manufacturer
Adam TechDescription
PCB MOUNT PIN HEADER (W/OUT POLA
Datasheet
DatasheetPackage
-
In Stock
94,418 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
DME-04-S2-S
DME-04-S2-S
lmages are for reference only.Payment Methods
Delivery Services
Connector Header Through Hole 4 position 0.250" (6.35mm)
Quick Inquiry
DME-04-S2-S
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Male Pins |
| Manufacturer | Adam Tech |
| Series | DME |
| Packaging | Bag |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Header |
| Contact Type | Male Pin |
| Pitch - Mating | 0.250" (6.35mm) |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Row Spacing - Mating | - |
| Number of Positions Loaded | All |
| Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | Locking Ramp |
| Contact Length - Mating | - |
| Contact Length - Post | 0.157" (4.00mm) |
| Overall Contact Length | - |
| Insulation Height | 0.581" (14.76mm) |
| Contact Shape | Circular |
| Contact Finish - Mating | Tin |
| Contact Finish Thickness - Mating | - |
| Contact Finish - Post | Tin |
| Contact Material | Phosphor Bronze |
| Insulation Material | Polyamide (PA66), Nylon 6/6 |
| Features | - |
| Operating Temperature | -40°C ~ 105°C |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-2 |
| Insulation Color | Natural |
| Current Rating (Amps) | 12A |
| Voltage Rating | - |
| Mated Stacking Heights | - |
| Contact Finish Thickness - Post | - |
| Applications | - |
| Base Product Number | DME-04 |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | DME-04-S2-P-S | DME-02-S2-P-S | DME-02-S2-S | DME-03-S2-P-S |
| Manufacturer | Adam Tech | Adam Tech | Adam Tech | Adam Tech |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | PCB MOUNT PIN HEADER (W/ POLARIZ | PCB MOUNT PIN HEADER (W/ POLARIZ | PCB MOUNT PIN HEADER (W/OUT POLA | PCB MOUNT PIN HEADER (W/ POLARIZ |
| Series | DME | DME | DME | DME |
| Packaging | Bag | Bag | Bag | Bag |
