DMN3055LFDBQ-7
lmages are for reference only.DMN3055LFDBQ-7
MOSFET 2N-CH 30V 5A 6UDFN
Datasheet6-UDFN Exposed Pad
70,864 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Mosfet Array 30V 5A (Ta) 810mW (Ta) Surface Mount U-DFN2020-6 (Type B)
DMN3055LFDBQ-7
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Technology | - |
| Configuration | 2 N-Channel (Dual) |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 5A (Ta) |
| Rds On (Max) @ Id, Vgs | 40mOhm @ 3A, 4.5V |
| Vgs(th) (Max) @ Id | 1.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 11.2nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 458pF @ 15V |
| Power - Max | 810mW (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 6-UDFN Exposed Pad |
| Supplier Device Package | U-DFN2020-6 (Type B) |
| Base Product Number | DMN3055 |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
 |
 |
|
| Part Number | DMN3055LFDB-13 | DMN3055LFDB-7 | DMN3055LFDBQ-13 | DMN3003LCA8-7 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET 2N-CH 5A 6UDFN | MOSFET 2N-CH 5A 6UDFN | MOSFET 2N-CH 30V 5A 6UDFN | MOSFET 2N-CH 30V 25A X2-TSN6025 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) |
