P-Channel 20 V 115A (Tc) 1W (Ta) Surface Mount POWERDI3333-8
DMP2004UFG-13
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20 V |
| Current - Continuous Drain (Id) @ 25°C | 115A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 10V |
| Rds On (Max) @ Id, Vgs | 3mOhm @ 15A, 10V |
| Vgs(th) (Max) @ Id | 1.1V @ 250µA |
| Vgs (Max) | ±12V |
| Input Capacitance (Ciss) (Max) @ Vds | 3840 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 1W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | POWERDI3333-8 |
| Package / Case | 8-PowerVDFN |
| Base Product Number | DMP2004 |
| Gate Charge (Qg) (Max) @ Vgs | 83 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | DMP2004UFG-7 | DMP2004K-7 | DMP2004KQ-7 | DMP2004TK |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET BVDSS: 8V~24V PowerDI3333 | MOSFET P-CH 20V 600MA SOT23-3 | DIODE | DIODE |
| Series | - | - | - | - |
| Packaging | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Bulk |
